USE AND MAINTENANCE MANUAL
Road Sweeper S150
Page 33 of 54
4.8.
SUCTION MOUTH
Picture 14 Picture 15
Picture 16
The suction mouth is located at the front of the machine close to the front brushes. [See Picture 14]
Operation
Its movement occurs simultaneously with the brushes by pressing the up-down button POS 1.
[See Picture 16]
In the presence of large objects to be sucked it is possible to lift the flap (so to increase the
input of the loading mouth) via a pedal in the cab at the bottom left. Release the pedal to lower
the flap. [See Picture 15]
When reversing the suction mouth is lifted automatically.
