USE AND MAINTENANCE MANUAL
Road Sweeper S150
Page 40 of 54
4.13.
HEATING SYSTEM AND AIR CONDITIONER
Operation
-To enable the heating open (turning counter-clockwise) the adjuster at the left side of the cabin
floor, between the seat and the heating column, when it is in position A [See Picture 26].
Activate the ventilation through the adjuster POS 2. [See Picture 25].
- To switch the air conditioner on bring the adjuster to position C [See Picture 26]. Activate the
ventilation with the adjuster POS 2. Adjust the temperature with the controller POS1. [See
Picture 25]
Picture 26
Picture 25
