Fiori DB 260 - Air-Conditioner Air-Conditioner; Operation Operation

162
6
OPTIONAL EQUIPMENT
id.:
DB 260 REV. 00 02/07/2015
6.3 AIR-CONDITIONER
The air conditioner allows air cooling inside the driver’s cabin.
2
C
C
B
A
During the summer, or when temperatures are higher than 20°C, it is best to shut off the heating circuit, espe-
cially if you intend to use the A/C (optional).
Slacken off nut A, unscrew nut B and rotate scale C; cock D is located on the chassis under the cab, turn the
lever 90° CW to close the circuit.
B
A
C
CLOSED
D
1
6.3.1.
OPERATION
OPERATION (fi g. 2)
- Start the engine.
- Adjust the fan speed as desired using the knob on the switch A.
Note: the air conditioner is only activated if the fan speed is set at least to the fi rst level.
