MAINTENANCE
id.:
DB 260 REV. 00 01/07/2015
- Relays located next to the engine’s PTO (fi g. 34)
CAUTION: If a fuse blows or a relay burns, fi nd the cause before replacing it with a new one.
16 - Starter motor/stopping relay.
17 - Main engine relay
5.12.2 ELECTRONIC DASHBOARD WARNING LIGHTS
(fi g. 35)
In the event of malfunctioning of the electronic panel, contact the nearest AUTHORISED FIORI SERVICE
CENTRE or FIORI SPARE PARTS DEPARTMENT directly. In the event of replacement, the panel is delivered
already programmed.
CAUTION: Note down the hours of operation before replacing the electronic control panel.
08 - K108 - Micro-relais de validation démarrage sans présence d’eau dans le gazole.
09 - K109 - Micro-relais compresseur de climatisation (option).
10 - K110 - Micro-relais phares de travail arrière.
11 - K111 - Micro-relais de commande signal sonore de fonctionnement engin.
12 - K112 - Module de diodes de validation point mort et changement de vitesse.
13 - K113 - Intermittence clignotants.
14 - K114 - Micro-relais a disposition.
15 - K115 - Micro-relais a disposition.
35
34
16
17
