SPARE PARTS - Control Unit
39
FIREBIRD ‘S’ RANGE
CONTROL UNIT MODELS & PART NUMBERS
ITEM COMPONENT Qty Heat Pac Kitchen
1 Dual Stat 1
2 Frost Stat 1
3 Control Box Cover 1
4 Control Box 1
5 Control Box Mounting 1
6 Over Heat Thermostat 1
7 Strip Connector 1
8 Label 1
9 Socket [Wieland] 1
10 Plug [Wieland] 2
11 Open Grommet 3
12 Blank Grommet 2
TLSC542788
TLM2257
119183
119184
119185
FC03154
FC03144
W-1001
FC031542
FC03143
MO10281
MO11321
TLSC542788
TLM2257
119183
119184
119185
FC03154
FC03144
W-1001
FC031542
FC03143
MO10281
MO11321
12
12
3
4
Temperature
Control Dial.
5.Neutral For Frost Stat.
4.Permanent LiveFrost Stat
7.Live From Frost Stat
1.Lamp Neutral
3.Lock out Lamp.
2.Mains On Lamp.
6.Earth For Frost Stat.
E
13
24.Return From Pressure Switch.
23.To Pressure Switch.
22.Pump Earth.
21.Pump Earth.
20. Pump Live
1
15
16
14
18
19
17
4
2
3
7
6
5
Pressure
Switch
Circulating
Pump
22
21
20
24
23
10
9
8
12
11
8
7
12
4
5
5
6
9
10
12
11
