FireClass Prescient III - 11 Panel Exploded View

EQUIPMENT: FIRECLASS Prescient III WRITTEN BY: RKP
PUBLICATION: OMFCPRES3IN CHECKED BY: AP
ISSUE No. & DATE: 0 02/02/12
PAGE 36 of 43
11. Panel Exploded View
KEYSWITCH CONNECTOR
10K RESISTOR
DOOR LOCK
LOGO
BREAK GLASS LEAD
KEYSWITCH MOUNTING NUT
BACKBOX ENCLOSURE
DOOR
MOTHERBOARD PCB
MANUAL RELEASE CONNECTOR
CHASSIS EARTH CABLE
DOOR EARTH CABLE
CHASSIS
8 WAY EARTH BAR
KEYSWITCH
NOTE:-TERMINAL BLOCK POSITION. (L.H.S. CONNECTIONS 1,2,3,4.)
1234
BREAK
GLASS
PANEL
HALON BREAK GLASS UNIT
PURSPEX
COVER
RETAINING
PANEL
MAINS TERMINAL BLOCK - 3A15 FUSE
MAINS TERMINAL LABEL
PSU EARTH CABLE
DISPLAY BOARD
MEMBRANE
INSERTS
5A POWER SUPPLY
