Fireray 3000 User Manual

Green - flash/stop
Green - flash/stop
12
Signal
increased
Signal
decreased
Amber -
flash/stop
LCD value
decreases
Amber - flash/stop
Green - flash/stop
Green - short/long
flash
LCD = 180
LCD value
increases
LED - no flash
LCD = between 2
and 178
Adjust one
thumbwheel by
1/4 turn.
Adjust same thumbwheel by
1/4 turn in the opposite
direction.
Press tick to accept
alignment
Repeat step 4 for the other
thumb-wheel
Adjust same thumbwheel by 1/8 turn in
the opposite direction
Adjust same thumbwheel by 1/4 turn
in the same direction. Release thumb-
wheel and wait 1 second.
(SEE NOTE 1)
(SEE NOTE 1)
Reduce Tx
power
Tx
Tx
Tx
Tx
Tx
Rx
Rx
View LEDs on Rx or
LCD value
View LEDs on Rx or
LCD value
Step 4
NOTE 1: Value can be
between 2 and 178.
A higher value means a
better alignment.
From Step 3

Fireray 3000 Specifications

General

Detection Range	Up to 100m
Operating Temperature	-10°C to +55°C
IP Rating	IP65
Alarm Relay	1A @ 30V DC
Fault Relay	1A @ 30V DC
Detection Principle	Infrared beam
Response Time	10 seconds
Alarm Output	Relay
Current Consumption	≤25mA (standby), ≤45mA (alarm)
