Fireray 5000 User Manual

15
20. Troubleshooting
E-10
Reflector Not
Found during
Auto-Align
• Ensure clear line of sight
from Detector to Reflector for
a radius of 0.5m
• Ensure correct distance has
been selected
• Ensure correct Reflectors
have been used
• Realign Detector
E-11 Auto-Align Failed
• Ensure clear line of sight
from Detector to Reflector for
a radius of 0.5m
• Ensure correct distance has
been selected
• Ensure correct Reflectors
have been used
• Realign Detector
E-12
Cannot Zero
During ‘S-00’ in
‘Set’
Signal did not
decrease when
‘S-00’ selected
• Ensure Reflector was
completely covered with a
non-reflective material
• Re-align Detector using
Auto-Align
E-13
No Signal During
‘S-01’ in ‘Set’
Signal did not
increase when
‘S-01’ selected
• Ensure Reflector was
uncovered when ‘S-01’ was
selected
E-14
‘Centre’ Stage of
Alignment Failed
Detector has
aligned on
something other
than the
Reflector
• Ensure clear line of sight
from Detector to Reflector for
a radius of 0.5m
E-21
Power too low
fault
• Check power supply to
Controller
E-24
Detector not
compatible
• Refer to manufacturer for
technical assistance
E-26
Internal
controller fault
• Refer to manufacturer for
technical assistance
E-00
AIM not
recognised
• Refer to manufacturer for
technical assistance
E-01
Detector
Communications
Error
• Check wiring between
System Controller and
Detector (Voltage to
Detector should be 11—
13V)
E-02
Detector is
connected but
not ‘Found’
• Follow ‘Find’ process and
align if necessary
E-03
Compensation
limit reached
• Clean and realign system
E-04
Detector missed
too many
readings
• Check voltage to Controller.
• Check voltage to Detector is
>11V
E-05
Detector is not
aligned
• Follow alignment procedure
E-06
Rapid
Obscuration Fault
• Ensure clear line of sight
from Detector to Reflector
E-07
Signal Too High
Fault
• Ensure clear line of sight
from Detector to Reflector
• Ensure there is no strong
light on Detector
E-08
Compensation
Level Not Zero
during ‘SET’
• Re-align Detector using
Auto-Align
E-09
Signal Strength
Out of Range
when ‘SET’
selected
• Ensure Reflector uncovered
when ‘SET’ selected
• Ensure clear line of sight
from Detector to Reflector
for a radius of 0.5m
• Ensure correct distance has
been selected
• Ensure correct Reflectors
have been used
• Realign Detector

Fireray 5000 Specifications

General

Operating Temperature	-10°C to +55°C
IP Rating	IP65
Detection Principle	Infrared beam
Alarm Output	Fire and Fault relays
Certification	EN54-12
Wavelength	Infrared
