Fireray 5000 User Manual

16
Dimensions
Width,
mm (in)
Height,
mm (in)
Depth,
mm (in)
Weight,
kg (lb)
System Controller, including base 202 (8.0) 230 (9.1) 81 (3.2) 1.0 (2.2)
Detector, including 'easy fit' base 135 (5.3) 135 (5.3) 135 (5.3) 0.5 (1.1)
Reflector (Single) 100 (3.9) 100 (3.9) 10 (0.4) 0.1 (0.2)
Parameter Value
Operating Voltage 14—36V DC
Operating Current – Normal Operation
(including fire or fault activated)
5.5mA - 1 Detector
8mA - 2 Detectors
Operating Current – Alignment modes - HiA
Alignment modes - LoA
36mA
5.5mA / 8mA
Fire Threshold Range
0.45—3.98 dB
10—60%
Delay to Fire 2—30 s
Delay to Fault 2—30 s
Operating Distance between Detector and Reflector 8—100 m
Maximum angular misalignment of Detector ± 0.3 Deg
Maximum angular misalignment of Reflector ± 5 Deg
Maximum angular movement of Detector head ± 3.5 Deg
Optical wavelength 850 nm
Rapid Obscuration Fault threshold 87%
Operating Temperature (UL Approved) 0—+37.8 Deg C
Operating Temperature (EN54-12 Approved) -10—+55 Deg C
Operating Temperature (FM Approved) -20—+55 Deg C
Storage temperature -40—+85 Deg C
Relative Humidity (non condensing) 93%
IP Rating IP54
Relay Contact Rating
VFCO, 2A@30VDC
Resistive
Maximum Cable Length (Controller to Detector) 100 m
Cable Gauge
24—14 AWG
0.5—1.6 mm
Housing Flammability rating UL94 V0
21. Technical Specifications
Document Number: 0044-033-05-EN

Fireray 5000 Specifications

General

Operating Temperature	-10°C to +55°C
IP Rating	IP65
Detection Principle	Infrared beam
Alarm Output	Fire and Fault relays
Certification	EN54-12
Wavelength	Infrared
