4
VA Pilot Duty ratings permit the connection of relays, solenoid valves, lamps, etc. whose total oper-
ating load does not exceed the published rating and whose total inrush does not exceed 10 times the
rating.
Running and locked rotor ratings are intended for motors. VA and VA Pilot Duty loads may be added
to a motor load provided the total load does not exceed the published rating.
OPERATIONAL TIMINGS
The BurnerPRO is pre-programmed from the factory with a set of operational timings necessary for
the safe operation of the burner system. However, operational timings can be modified via the mod-
bus port. The operational timings are governed by regional and local codes. It is important that the
appropriate operational timing is selected for the burner application.
Table 1: Timing Information
See Table 7 on page 23 for expanded timing information.
Times are in seconds BURNERPRO SERIES TIMINGS
TIMING DESCRIPTION S1 S2 S3 S4 S5 S6
t1 Purge time 35.53137603730
t3' Pre-ignition time (piloted) 4 6 2.5 2.5 2.5 1
TSA’ Ignition safety time (PTFI) 2 3 5 5 5 10
t6 Post-purge time 12 18 15 15 15 15
t9 Interval between Main Fuel Piloted and removal of Pilot (MTFI) 2 3 5 5 5 10
FFRT Flame Failure Response Time (FFRT) 1.0 4 4
NOTICE: This equipment generates and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual may cause interference to
radio communications. It has been tested and found to comply with the limits for a Class B
computing device pursuant to Subpart J of part 15 of FCC Rules, which are designed to
provide reasonable protection against such interference when operated in a commercial/
industrial environment.
