Fireye BurnerPRO - BurnerPRO LED Error;Lockout Codes (Continued); Lockout Code Mapping (33-63)

42

The table above shows the various required LED error/lockout codes displayed on the BurnerPRO after a fault or error
has occurred.
33 STANDBY FALSE FLAME
●●
RED
34 T21/EMERGENCY LOCKOUT
●● ●
RED
35 SW WDT RESET
●●
RED
36 SW RESET
●● ●
RED
37 INPUTS WAITING TIME FAULT
●● ●
RED
38 VALVE PROVE TEST TIME 1 FAIL
●●● ●
RED
39 VALVE PROVE TEST TIME 2 FAIL
●●
RED
40 HARDWARE RESET
●●●
RED
41 UNUSED
●● ●
RED
42 MAIN LOOP STUCK FAULT
●● ● ●
RED
43 SUPV LOOP STUCK FAULT
●● ●
RED
44 SUPV TIMER2 FAULT
●●● ●
RED
45 MAIN AC PEAK MISSING FAULT
●●● ●
RED
46 SUPV AC PEAK MISSING FAULT
●●●● ●
RED
47 UV PULSE INPUT MISSMATCH
●●
RED
48 SUPERVISORY MCU ADC FAULT
●●●
RED
49 MAIN MCU ADC FAULT
●●●
RED
50 IGNITION FEEDBACK FAULT
●● ● ●
RED
51 PILOT FEEDBACK FAULT
●●●
RED
52 MAINP FEEDBACK FAULT
●● ●●
RED
53 FEEDBACK WAITING TIME EXPIRE
●● ● ●
RED
54 MAIND FEEDBACK FAULT
●●● ● ●
RED
55 INTERRUPT DIAG FAULT
●●●
RED
56 UV FALSE FLAME ERROR
●●●●
RED
57 FR FALSE FLAME ERROR
● ●●●●
RED
58 OPEN FEEDBACK READING FAULT
●●●●●
RED
59 ADJACENT PIN SHORT FAULT
● ●●●
RED
60 LOCAL RESET DEBOUNCE FAULT
●●●● ● ●
RED
61 POC OPEN FAULT
● ●●●
RED
62 STRONG UV FLAME FAULT
●● ●●●
RED
63 SPI CRC FAULT
●
RED
