Replacing the E-216 bungee shock cord
Step 1. Remove the Perspex
cover from rear of upper
frame. Disconnect sensor
lead.
Step 2. Move the rowing handle
from the S-bend handle catch to
a point where it is resting on top
of the tank . This helps line up
the bungee cord hole for easier
removal/replacement. Detach
bungee cord from lower rear at-
tachment point.
Step 3. Unwrap the bungee
cord from all of the bungee
pulleys.
1
2
3
