Replacing the E-216 bungee shock cord
Step 4. Next, remove the magnetic ring. To loosen the rear mainshaft bolt holding the magnetic ring in place, it is neces-
sary to keep the mainshaft and impeller assembly from turning with the bolt. Open the right rear tank plug, and insert a
wrench wrapped in a lint free cloth (to protect the electroplating finish on the blades) to catch the impeller blade and allow
the rear mainshaft bolt to be loosened as shown below right with a 6mm Allen key. Caution: Do not allow a dissimilar
metal to directly contact the impeller blade. Premature rusting could occur . Cover any tool inserted the tanks with a lint
free cloth and keep fingers clear.
WARNING
Do not insert fingers into tank!
