Replacing the E-216 bungee shock cord
Step 5. After removing the magnetic ring, the
bungee cord will be accessible. Pull through the
rope/bungee pulley and remove. Note that the
rower handle should be resting on top of the tank
(as shown in step 2) for the bungee hole to line
up. Thread new bungee cord through and pull un-
til knotted end is held securely in the slot.
Step 6. Once the bungee cord is in position, make
two wraps on the rope/bungee pulley in a clockwise
direction, checking to see that the bungee cord
tracks in the proper grooves. Make sure the
bungee is wrapped behind the Dyneema rope when
threading to the first bungee pulley (shown next
page).. Once the bungee has reached the position
shown below, you may begin to rewrap the bungee
around the bungee pulleys, starting with the upper-
right rear pulley.
5
6
To Next Page
