Replacing the E-216 bungee shock cord
5
6
7
8
Finish the bungee rewrap by tying
off the bungee. You may elect to
not use a tie wrap as the metal tab
is designed as a stand alone at-
tachment point. Thread the
bungee through to desired tension
and thread the bungee end through
the upper hole as shown.
Reattach the magnetic ring.
Tighten securely.
Finally, reattach the sensor
lead and replace the Per-
spex rear cover.
