First Degree Fluid FR-E216 - Page 7

Step 8. Install rear rubber bump stop
using the two M6X10mm screws
.
8
Step 9. Attach
the rear seat rail
leg using 2x
M8X60mm
bolts, M10
washers and
internal support
bracket. Insert
rubber seat rail
end cap (not
shown).
Step 7. Install the rower seat. (Make sure seat indentation is
facing rearward as pictured)
7
9
Rear Leg
Internal support
bracket
M8x60mm
Bolts and 10mm
washers
