CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
Connector 3 (CN2), 20-Pin: Programmable Output Channel (POC)
IMPORTANT: Odd Pin numbers 3 through 19 are programmable for up to 19 different output types. Refer
to Special Option Group 2 for details.
Pin 1 Blue - 250mA negative (-) output when armed and during remote start (while running). This wire is
pre-wired to the anti-grind/starter-kill relay. Caution: When this wire is being used to trigger
aftermarket accessories it must be diode isolated.
Pin 2 Orange/Black - Parking Light Reminder (-) input that monitors the vehicle’s parking lights.
Pin 3 Green/White [POC 1] - Parking light 250mA negative (-) output. The proper wire will test (-) when
the parking light switch is in the on position.
Pin 4 Light Blue – Parking / Emergency brake negative (-) input. This input is required for manual
transmission/reservation and turbo-timer mode. The proper wire will provide a (-) trigger when
parking / emergency brake is set and ignition is on.
Pin 5 Red/Black [POC 2] – 2nd Starter 250mA negative (-) output. This output provides a negative (-)
trigger output during remote start crank.
Pin 6 Light Blue/White - Brake 12V positive (+) input. This input must be connected as it provides a shut
down for the remote start. The proper wire will test (+) 12V while the foot brake is pressed.
Pin 7 Green [POC 3] - 2nd Ignition 250mA negative (-) output. This output provides a negative (-) trigger
upon remote start, throughout the crank and during remote start.
Pin 8 Violet/Black - Trunk negative (-) input. This is an optional input that will monitor when the vehicle’s
trunk has been opened. The proper wire will provide a (-) trigger while the trunk is open.
Pin 9 White/Black [POC 4] - 2nd Accessory 250mA negative (-) output. This output provides a negative (-)
accessory trigger that will drop out during crank.
Pin 10 Red/White - Door trigger input. This wire monitors negative (-) or positive (+) trigger door-pins. The
proper wire will provide a (-) trigger or a (+) trigger only when the doors are opened. You will need
to test the wire for proper polarity and set the jumper on the control module for the corresponding
polarity. IMPORTANT: This wire is required for manual transmission remote starts.
