CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
2-01 Tach Sensing Method – This option will adjust the method at which tach signal is used by the control
module to control the starter output (yellow wire CN1) the default option will minimize over-crank
during remote start for most applications. The low threshold will release the starter at a lower tach
signal than what was programmed initially to reduce any over-crank that may occur.
2-02 Turbo Mode – This option will adjust the run time after Turbo mode has been engaged. The e-brake
and door trigger inputs must be connected and the turbo mode feature must be activated/
deactivated by the remote according to the individual remote users guide. Once activated by the
remote the feature may be engaged by setting the e-brake. The vehicle should stay running, after the
key is turned off, for the selected length of time.
2-03 Diesel Timer – This feature provides an alternative solution to a hard wired glow plug input. You can
use option 2 for a default wait to start of 12 seconds, option 3 for 7 seconds (or manual adjust time
with OP500). Option 4 will give your control module a 250mS delay between accessory power
up and ignition power up which may be required for certain GM vehicles to avoid starting
complications.
2-04 Trigger Start – This feature changes the number of times required for a negative (-) pulsed input (min
of 60mS per pulse) on the trigger start input wire (pink wire CN3). If option 3 is selected and OEM
remote control feature is available through data the Control Module will accept 3 OEM lock
commands to activate the start sequence.
2-05 Cold or Hot Start – This option turns on the cold/hot starting features. This option works in
conjunction with 2-6, 2-8 and 2-9. The thermister must also be connected the brain.
2-06 Timer Start or Interval Between Cold Start - This feature dictates the time interval at which the control
module will either remote start or if using feature 2-05 it will check the temperature and remote start.
Default 1: Will start every 3 hours until the vehicle is remote started or started by key and run for 4
minutes.
Option 2: Will start every 1.5 hours until the vehicle is remote started or started by key and run for 4
minutes.
Option 3: Will start at the time specified on the 2 way remote once within 24 hours and run based
on Option 2-07. (Only works on 2 Way LCD remotes)
Option 4: Will start once every 24 hours if the temperature falls below Option settings 2-08 or
above Option settings 2-09.For example, if you want your car to start and run 25 minutes when the
temperature falls below 32°F, you need to set up the following options: For example, if you want
your car to start and run 25 minutes when the temperature falls below 32°F, you need to set up the
following options:
1) Option 2-05 (Cold Start) turned on,
2) Option 2-06-IV (24 hr. repeat) turned on,
3) Option 2-07-II (25 min run-time) turned on,
4) Option 2-08-IV (Temp 32°F) turned on,
Copyright 2012 Firstech, LLC.
Page 24
