CM6200 Install Guide
Starter System
www.firstechonline.com | www.compustar.com
3-05 Anti-Jacking – This feature requires the starter-kill relay to be wired to the ignition vs. the starter wire.
Default 1: Acts like starter-kill: removes power from the ignition, which allows the car to crank but
not start.
Option 2: Turns on anti-jacking: when the remote panics the system, power from the ignition will be
removed at the end of the 30 second siren duration, thereby disabling the vehicle.
Option 3 & 4: no longer available
IMPORTANT: When using ignition-kill on manual transmission vehicles Option 2 will need to be
utilized. Option 2 disables the anti-grind circuit while the vehicle is remote-started; if the anti-grind
circuit is active and the start-kill relay is installed in the ignition, the relay will “buzz” while remote-
started.
3-06 Factory Alarm Option- This feature is default to off, when set to option 2 the security features of the
CM6200 will be activated.
3-08 Horn output- This feature will change the behavior of horn output (white wire POC8 CN3).
3-09 Siren Output - This Feature will change the behavior of the siren output (brown wire CN3) (only
available with feature 3-06 option 2)
3-10 Valet – This option changes valet modes.
Default 1: Key on/off five times or remote valet (I + III for 0.5 seconds) with key in the on position.
Option 2: Key on/off five times or remote valet (I+III for 0.5 seconds) – key does not need to be in
the on position.
Option 3: Secure valet: RPS Valet or remote valet (I+III for 0.5 seconds) – this option prevents the
system from being put into valet via key on/off five times. To set up the RPS Valet feature, review the
“Placement and Use of Components” section.
3-11 Auxiliary settings – The Auxiliary settings adds five additional independent auxiliary outputs for a total
of seven with this option turned on. Special Option Group 1 allows for independent timing of these
outputs.
3-12 VAC (Ventilation/Air-conditioning)- (Thermister required)This feature when used in conjunction with
a POC programmed to value 22 (VAC) will provide an 800mS pulsed output to activate any module
or AC control necessary to help cool the vehicles interior. (Option 4 will provide a latched output for
the entire runtime).
3-13 Defroster Output Temperature Control - This feature will allow the user to set the defrost to activate
every time during remote start or below 32 or 42 degrees F (0 or 5.5 degrees C) based on the
option selected.
3-14 Defroster Timing - Some vehicles need a pulse to activate the defroster, others will need a constant
output to remain active, you can use this option to adjust the duration of the defroster output.
Copyright 2012 Firstech, LLC.
Page 26
