Fisher & Paykel DW60FC1 Service Manual

8
2 SPECIFICATIONS
2.4 Component Specification
Component Models
Electrical Data DW60FC1 DW60FC2 DW60FC4 DW60FC6
Voltage
Wattage
Amps (max)
230-240 230-240 230-240 230-240
1900-2050 1900-2050 1720-2050 1720-2050
10 10 10 10
Wash Pump
voltage
wattage
Resistance
Outlet pressure (mbar)
Pump rate (litres/min)
230-240 230-240 220-240 230-240
65 65 82 95
127+- 5% Ω 127+- 5% Ω 127+-5% Ω 47+-5% Ω
300 300 300 340
52 52 52 35
Drain Pump
Voltage
Wattage
Resistance
Thermal protection
pump rate (litres/min)
220-240 220-240 220-240 220-240
25 25 25 25
202 Ω 202 Ω 202 Ω 202 Ω
145 +-5 °C 145 +-5 °C 145 +-5 °C 145 °C
20 (L/Min) 20 (L/Min) 20 (L/Min) 20 (L/Min)
Inlet Valve
Voltage
Wattage
Resistance
Flow rate (litres/min)
220-240 220-240 220-240 220-240
6 6 6 6
4.5K Ω 4.5K Ω 4.5K Ω 4.5K Ω
2.5 L/Min 2.5L/Min 2.5L/Min 2.5L/Min
Heating Element
Voltage
Wattage
Resistance
Over heat protection (self reset)
Over heat protection (non reset)
230 230 230 230
1800 1800 1800 1800
29.4 Ω 29.4 Ω 29.4 Ω 28.7 Ω
100 +-5 °C 100 +-5 °C 100 +-5 °C 100 +-5 °C
206 +-10 °C 206 +-10°C 206 +-10°C 206 +-10°C
Turbidity Sensor
No Yes No
Temperature Sensor
Temperature (max/min)
Resistance range (+-1%)
100-0 100-0 100-0 100-0°C
10K Ω @25 °C 10K Ω @25 °C 10K Ω @25 °C 10K Ω @25 °C
Flow Meter
Pulse rate (per litre) 218 +-6 218 +-6 218 +-6 218 +-6

Fisher & Paykel DW60FC1 Specifications

General

Brand	Fisher & Paykel
Model	DW60FC1
Category	Dishwasher
Language	English
