STEP 3
Assemble the extension pipe + pressure regulator group to the range manifold interposing the gasket supplied.
The regulator cover must be ordiented toward the front side of the range.
IMPORTANT: use two wrenches to tighten the connection.
STEP 4
Fix the “B” bracket on the back of the range
by the 2 (two) screws supplied with the kit
for gas connection.
The regulator cover must be ordiented
toward the front side of the range.
Fig. 2.4
Fig. 2.5
B
B
