Type 399A-161-112
6
Figure 23. Type 161AY and 161AYM Pilot Assemblies
B2631
• Replace "Figure 23. Types 161Y and 161YM Pilots" on page 38 with the following:
TYPE 161AY PILOT ASSEMBLY
EXPANDED VIEW OF BODY AREA SHOWING THE
BODY SEAL O-RING AND BACKUP RING PLACEMENT
BACKUP RING (KEY 50)
BODY SEAL O-RING (KEY 11)
BODY (KEY 1)
