Fisher i2P-100 User Manual

Instruction Manual
D103198X012
i2P-100 Transducer
July 2014
25
Key Description
Mounting Parts
Note
Contact your Emerson Process Management sales office for i2P‐100
mounting FS number.
Yoke Mounting
470 size 23 through 64
80 Mounting Bracket, steel
81 Washer, steel pl (4 req'd)
82 Cap Screw, steel pl (4 req'd)
480 Series actuator boss
80 Mounting Bracket, steel
81 Washer, steel pl (4 req'd)
82 Cap Screw, steel pl (4 req'd)
83 Screw, steel pl (2 req'd)
85 Mounting Bracket, Steel
86 Hex Nut, steel pl (2 req'd)
585C size 25 and 50
80 Mounting Bracket, steel
81 Washer, steel pl (4 req'd)
82 Cap Screw, steel pl (4 req'd)
83 Screw, steel pl (2 req'd)
585C (470) size 60, 68, 100, and 130 ; 657 and 667 size 30, 34,
40, 45, 50, 60, 70, 80 & 87; 1051 and 1052 size 40, 60 and 70;
1061 all sizes
80 Mounting Bracket, steel
81 Washer, steel pl (4 req'd)
82 Cap Screw, steel pl (4 req'd)
83 Screw, steel pl (2 req'd)
84 Spacer
Key Description
Casing Mounting
657 and 667 size 30, 34, 40, 45, 50 and 60
80 Mounting Bracket, steel
81 Washer, steel pl (2 req'd)
82 Cap Screw, steel pl (2 req'd)
83 Screw (req'd)
657 and 667 size 70
80 Mounting Bracket, steel
81 Washer, steel pl (2 req'd)
82 Cap Screw, steel pl (2 req'd)
83 Screw (2 req'd)
1051 and 1052 size 20, 33, 40, 60 and 70
80 Mounting Bracket, steel
81 Washer, steel pl (2 req'd)
82 Cap Screw, steel pl (2 req'd)
83 Screw (req'd)
1250 and 1250R all sizes
80 Mounting Bracket, steel
81 Washer, steel pl (2 req'd)
82 Cap Screw, steel pl (2 req'd)
87 Washer
91 U‐Bolt (2 req'd)
92 Hex Nut (req'd)
Pipestand Mounting
80 Mounting Bracket, steel
81 Washer, steel pl (4 req'd)
82 Cap Screw, steel pl (2 req'd)
88 Pipe Clamp, steel pl
Surface Mounting
80 Mounting Bracket, Steel
82 Cap Screw
