Instruction Manual
D103198X012
i2P-100 Transducer
July 2014
4
Table 1. Specifications (continued)
Electrical Housing:
When Remotely Vented No Remote Venting
CSA—Type 4X Encl.
FM—NEMA 4X
ATEX—IP66
IECEx—IP66
CSA—Type 3 Encl.
FM—NEMA 3
ATEX—IP64
IECEx—IP64
Other Classifications/Certifications
GOST
‐R—Russian GOST‐R
INMETRO— National Institute of Metrology, Quality,
and Technology (Brazil)
KGS—Korea Gas Safety Corporation (South Korea)
NEPSI— National Supervision and Inspection Centre
for Explosion Protection and Safety of
Instrumentation (China)
RTN—Russian Rostekhnadzor
Contact your Emerson Process Management sales
office for classification/certification specific
information
Connections
Supply and Output Pressure: 1/4 NPT internal
connection
Vent: 1/4 NPT internal
Electrical: Standard 1/2 NPT
Wire Size: 18 to 22 AWG
Adjustments
(1)
Zero and Span: Trim potentiometers (20 turn) for
zero and span adjustments are located under the
housing cap (see figure 10).
Switch: Allows input signal split range and
user‐configurable 0.14 to 2.3 bar (2 to 33 psig)
output.
Mounting Position
J Actuator J pipestand or J surface
Approximate Weight (Transducer Only)
2.5 kg (5.5 lbs)
Actuator Stroking Time
See figure 2
Declaration of SEP
Fisher Controls International LLC declares this
product to be in compliance with Article 3 paragraph
3 of the Pressure Equipment Directive (PED) 97 / 23 /
EC. It was designed and manufactured in accordance
with Sound Engineering Practice (SEP) and cannot
bear the CE marking related to PED compliance.
However, the product may bear the CE marking to
indicate compliance with other applicable European
Community Directives.
NOTE: Specialized instrument terms are defined in ANSI/ISA Standard 51.1 - Process Instrument Terminology
1. For other ranges, zero and span adjustments are needed.
2. The pressure and temperature limits in this document and any applicable standard or code limitation should not be exceeded.
3. Normal m
3
/hr—Normal cubic meters per hour (0_C and 1.01325 bar, absolute). Scfh—Standard cubic feet per hour (60_F and 14.7 psia).
4. Performance values are obtained using a transducer with a 4 to 20 mA DC input signal and a 0.2 to 1.0 bar (3 to 15 psig) output signal at an ambient temperature of 24_C (75_F).
Table 2. EMC Summary Results—Immunity
Port Phenomenon Basic Standard Test Level
Performance
Criteria
(1)
Enclosure
Electrostatic discharge (ESD) IEC 61000‐4‐2
4kV Contact
8kV Air
A
Radiated EM field IEC 61000‐4‐3
80 to 1000 MHz @ 10V/m with 1 kHz AM at 80%
1400 to 2000 MHz @ 3V/m with 1 kHz AM at 80%
2000 to 2700 MHz @ 1V/m with 1 kHz AM at 80%
A
I/O signal/control
Burst (fast transients) IEC 61000‐4‐4
1 kV
A
Surge IEC 61000‐4‐5
1 kV (line to ground only, each)
A
Conducted RF IEC 61000‐4‐6 150 kHz to 80 MHz at 3 Vrms A
Specification limit = ±1% of span
1. A=No degradation during testing. B = Temporary degradation during testing, but is self‐recovering.
