6. Click on [Reset] to reset the Z-axis and lower the platform to the zeroposition.
When the platform is lowered to the bottom, tighten the four M6 screws No.1-4 in
sequence according to the figures shown.
7. Pull the A4 paper back and forth. Make
sure some resistance can be felt during
pulling.
8. Click on "+" to raise the platform
200-300 mm to complete the leveling.
N o.1
No.2
No.3
No.4
Tighten
10
Stop
Z:
-
+
mm22 00
Stop
Z:
-
+
mm22 00
