Product Layout
Body
Control Panel
01. Retractable Bounce Card
02. Retractable Wide Angle Diuser
03. Flash Head
04. Optical Slave Sensor
05. Focus Assist Beam
06. Hotshoe
07. LCD Panel
08. Lock Ring
09. Battery Compartment
10. USB Port for Firmware Upgrades
11. < MODE> Mode Selection Button
12. <ZOOM> Zoom Button
13. <SYNC> High-Speed Sync Button
14. <SLAVE> 51/52 Optical Slave
Button (in non-wireless mode)
15. < > Power Switch
16. < > Test Button/
Flash Ready Indicator.
17. <C.Fn> Custom Function Setting
Button (long press for 2 seconds)
18. < > Wireless Selection
Button (long press for 2 seconds)
19. <GR/CH> Group/Channel Button
(in wireless mode)
20. Select Dial
21. <SET> Set Button
MODE ZOOM SYNC SLAVE
SET
12
11
17
16
13
14
19
18
15
20
21
