4
08
05
06
11
07
09
10
12
04
03
02
01
13
1. Retractable Bounce Card
2. Retractable Wide Angle
3. Flash Head
4. Optical Control Sensor
5. R1 Wireless Control Port
6. Sync Cord Jack
7. Hotshoe
8. Dot-matrix LCD Panel
9. Lock Ring
10. Battery Compartment
11. USB Port for Firmware
Upgrades
12. Slave Flash Ready Indicator
13. External Power Supply
Socket
Body
Control Panel
14. <MODE> Mode Selection
Button / Lock button
15. < > Wireless Selection
Button
16. Select Dial
17. <SET> Set Button
18. ON/OFF Power Switch
19. < > Test Button / Flash
Ready Indicator
20. Function Button 1
21. Function Button 2
22. Function Button 3
23. Function Button 4
RST
SET
20
21
22
14
19
17
18
15
23
16
Name of Parts
