Entering PARAMETERS
1) Press the BRK key to return to the Main Menu then the 4
or 6 key to place the carrots around the par menu
selection and “Parameters” will appear on the lower line,
then press either of the ENTER keys.
2) The following screen will appear that offers you the
chance to change from Channel A or Channel B. Using
the 2 and 8 keys will change the Channel letter. When the
correct channel is displayed, press ENTER.
3) Using the keyboard, enter the Outside Diameter of the
pipe. Remember this is the OD of the pipe and a 2 inch
pipe is not 2 inches OD. Press ENTER once complete.
4) Using the keypad, enter the Wall Thickness of your pipe
then press ENTER once complete.
5) Using the 2 and 8 keys select the correct Pipe Material
from the list, then press ENTER.
6) Using the 4 or 6 keys, chose NO or YES to indicate if your
pipe has internal Lining, then press ENTER when the
correct selection has been made.
7) Using the keypad, enter the Roughness of the inside of
your pipe. Change the value according to the conditions of
the inner pipe wall and press ENTER. The default for a
clean pipe is 0.004”.
8) Using the 2 and 8 keys select the correct Medium from
the list, then press ENTER.
9) Using the keypad, enter the Medium Temperature of
the fluid running through your pipe then press ENTER.
This will complete the input of all the PARAMETERS for your application
All the PARAMETERS will be saved in internal memory and you will automatically be return to the
Main Menu.
>PAR< mea opt sf
Parameters
Parameters
For Channel A:
Outer Diameter
3.500 inch
Wall Thickness
0.216 inch
Pipe Material
Carbon Steel
Medium Temperature
68.0 F
To Next Page
