Flexim FLUXUS F706**-A2 Series User Manual

A Menu Structure FLUXUS F70x
UMFLUXUS_F7V4-6-2EN, 2017-10-01 179
input of the roughness of the material
confirmation that the changes are to be stored
This display will only be indicated if a new material has been entered or the
properties of an existing material have been changed.
Install Medium
selection of the displays for the input of media
Install Medium with Special Funct.\SYSTEM settings\Libraries\Extended Library = off
selection whether a user-defined medium is to be edited or deleted
selection of a user-defined medium
input of a designation for the selected medium
input of the sound speed of the medium
range: 500.0...3500.0 m/s
input of the range around the average sound speed of the medium
range: 50...999 m/s
input of the kinematic viscosity of the medium
range: 0.01...30 000.00 mm²/s
input of the operating density of the medium
Install Medium with Special Funct.\SYSTEM settings\Libraries\Extended Library = on
selection of the function for the temperature and pressure dependence of the
medium properties
selection of a user-defined medium
selection whether the user-defined medium is to be edited or deleted
This display will only be indicated if the selected medium already exists.
input of a designation for the selected medium
input of the constants for the longitudinal sound speed of the medium
The number of constants depends on the function selected above.
INIT-
resistant
Roughness
0.4 mm
Save changes
no >YES<
Special Funct. ↕
Install Medium
Install Medium
>EDIT< delete
USER Medium ↕
#01:--not used--
EDIT TEXT (↑↓← →
USER MEDIUM 1
c-Medium
1500.0 m/s
c-Medium=1500m/s
range +-150m/s
Kinem.Viscosity
1.01 mm2/s
Density
1.00 g/cm3
Edit Medium ↕
Basics:Y=m*X +n
USER Medium ↕
#01:--not used--
USER MEDIUM 2
>EDIT< delete
#2: Input Name:
USER MEDIUM 2
SOUNDSPEED
1500.0 m/s
