8 Start-up of the Transmitter
8.1 Switching on
8.2 Initialization
During an initialization (INIT) of the transmitter, the settings in the program branches Parameter and Output Options
and some of the settings in the program branch Special Funct. are reset to the default settings of the manufacturer.
For INIT-resistant settings, see annex A.
Proceed as follows to execute an initialization:
• While switching on the transmitter: keep keys BRK and C pressed.
• During the operation of the transmitter: press keys BRK, C and ENTER at the same time. A RESET is executed. Release
key ENTER only. Keep keys BRK and C pressed.
After the initialization, the remaining settings of the transmitter can be reset to the default settings and/or the stored mea-
sured values can be deleted.
8.3 Display
8.3.1 Main Menu
The selected program branch is displayed in capital letters and in angle brackets. The complete designation of the select-
ed program branch is displayed in the lower line.
Select a program branch by pressing key and . Press ENTER.
As soon as the transmitter is connected to the power supply, the display indicates which
transducer has been detected at which channel.
Afterwards, the serial number of the transmitter is displayed for a short time.
Data cannot be entered while the serial number is displayed.
After the transmitter is switched on, the main menu is displayed in the default language.
The language of the display can be set (see section 8.5).
After the initialization has been executed, the message INITIALISATION DONE is dis-
played.
Select yes to reset the remaining settings to the default settings or no to keep them at the
current settings.
Press ENTER.
If yes is selected, the message FACTORY DEFAULT DONE will be displayed.
Select yes to delete the stored measured values or no to keep them stored.
Press ENTER.
This display will only be indicated if measured values are stored in the data logger.
The main menu contains the following program branches:
• par (Parameter)
• mea (Measuring)
• opt (Output Options)
• sf (Special Function)
Note! By pressing key BRK, the measurement will be stopped and the main menu is selected.
Note! In this user manual, all program entries and keys are indicated with typewriter characters (Parame-
ter). The menu items are separated from the main menu by a backslash "\".
FLEXIM FLUXUS
F70x -XXXXXXXX
INITIALISATION
----DONE----
