S P E C I F I C A T I O N S A N D A R C H I T E C T U R E C H A P T E R 7
FLEX-5000 Architecture
The FLEX-5000 full duplex/triplex architecture is shown in Figure 177 below.
198  2003-2008 FlexRadio Systems
Figure 177: FLEX-5000 Full Duplex/Triplex Architecture
