17
Clave 23+ Instruction Manual v1.4
E88
Maintenance request from the
machine
Contact dealer or service company and have a
maintenance done.
9. Transportation and Storage
1. Turn off the sterilizer before transportation or storage. Pull out the plug. Let the
machine cool down.
2. Drain the distilled water tank and the used water tank.
3. Conditions for transportation and storage:
Temperature: -20 °C ~ +55 °C (all water must be removed if below 0 °C)
Relative humidity: ≤85%
Atmospheric pressure: 50kPa ~ 106kPa.
4. If shipped, the unit must be strapped to a pallet. Do not ship in the box alone.
10. Safety Devices
1. Circuit breaker: Protects the sterilizer against possible failures and damage to the internal
components.
Action: Interruption of the power supply. Requires a manual reset. If it trips again, contact a
service person.
2. Thermal cutouts on the main transformer windings: Protection against possible short
circuit and overheating of the main transformer winding.
Action: Interruption of the power to the transformer. Contact a service person.
3. Safety valve: Protection against possible sterilization over pressure.
Action: Releases steam and restores pressure inside the chamber to a safe level.
4. Safety micro-switch for the door status: Informs the user if the door is incorrectly closed.
Action: Signal indicates that the door is not closed properly.
5. Thermal switch on chamber heating elements. Protection against possible overheating of
the chamber.
Action: Interruption of the power supply to the chamber elements. Resets when it cools.
6. Thermal switch on steam generator heating elements. Protection against possible
overheating of the steam generator.
Action: Interruption of the power supply to the steam generator element. Resets when it cools.
7. Door safety lock. Protection against accidental opening of the door.
Action: Prevents accidental opening of the door during a sterilization cycle.
8. Self-leveling pressure system: Pressure system adjusts to a neutral pressure level in case of a
manual cycle interruption, alarm or power loss.
Action: Automatic restoration of the atmospheric pressure inside the chamber.
