Flight Dental Systems Clave 23+ - Technical Specifications; Unit Dimensions and Power Ratings; Operational Parameters; Physical and Environmental Data

6
Clave 23+ Instruction Manual v1.4
2. Technical Specifications
Item Parameter
Chamber Φ247mm x 450mm (9.72” x 23.6”)
Rated Voltage 110 VAC 60 Hz
Circuit breaker F20A
Nominal power 1600VA
Sterilization 121 °C / 134 °C
Capacity of the distilled water tank
~ 2.5 L (water at maximum level)
~ 0.5 L (water at minimum level)
Operation temperature 5 °C ~ 40 °C
Exterior dimensions
480mm (W) x 445mm (H) x 700mm (D)
18.9” (W) x 17.5” (H) x 27.6” (D)
Net weight 50kg. (110.2 lbs)
Noise level < 70db
Relative humidity Maximum 80%, non-condensing
Atmospheric pressure 76kPa ~ 106kPa
3. Package Contents
No. Item Quantity
1 Steam sterilizer 1
2 Instrument tray 4
3 Instrument tray rack 1
4 Instrument tray handle 1
5 Door adjustment tool 1
6 Draining hose 2
7 Instruction manual 1
8 Door seal 1
9 USB Drive 1
10 Power cord 1
11 ‘O’ Ring kit 1
