APPENDIX
Installation
The optional HEADSET ADAPTER install as follows.
q
Turns the power OFF, then disconnect the DC power cable.
w
Unscrew the 4 screws, then remove the bottom cover.
e
Insert the connector as shown below.
r
Mount the phone plug attachment together with the mobile
mounting bracket with 2 supplied screws.
