APPENDIX
Specifications
General
Frequency range: .......................................118.000 to 136.975 MHz
Channel spacing: .......................................*8.33 kHz / 25 kHz
Mode: .........................................................AM (6K00A3E)
Number of memory channels: ...................99
Acceptable power supply: .........................13.8 V or 26.4 VDC (Negative ground only)
Usable temp. range: ..................................-30 °C to +60 °C
Frequency stability: ...................................+/- 5 ppm
Current drain: .............................................TX: 6 A (max), RX: 6 A (max), Standby: 260 mA
Dimensions: ...............................................W 150 X D 190 X H 50 (mm)
Weight: .......................................................1700 g
Transmitter
Output power: ............................................9 W (carrier) typical, 36 W (P-P)
Modulation: ................................................Last stage modulation
Modulation limiting: ...................................70 to 100%
Audio harmonics distortion: ......................Less than 15% (at 85% modulation)
Hum and noise ratio: .................................More than 40 dB
Spurious emissions: ..................................-16 dBm or less
Antenna impedance: ..................................50
Ω
Receiver
Receive system: .........................................Double conversion superheterodyne
Intermediate frequency: .............................1st : 38.85 MHz (Upper) 2nd : 450 kHz (Lower)
Sensitivity (at 6dB S/N): ............................Less than 1uV
Squelch sensitivity: ....................................0.5uV (Threshold)
Selectivity
25 kHz channel spacing: .....................
More than ±8 kHz (at 6 dB)
Less than ±25 kHz (at 60 dB)
*8.33 kHz channel spacing: .................
More than ±2.778 kHz (at 6 dB)
Less than ±7.37 kHz (at 60 dB)
Spurious response rejection: ....................More than 60 dB
Audio output power: ..................................More than 15 W (at 4
Ω
)
Side tone: ...................................................More than 100 mW (at 600
Ω
)
Hum and noise: ..........................................More than 25 dB
Audio output impedance: ..........................External. Speaker 4
Ω
(4 to 8
Ω
)
Side tone 600
Ω
* Except USA version
