27.2.3.3
Commented
building
structures
This
section
includes
a
few
typical
examples
of
moisture
problems
on
low-slope
commercial
roofs.
Comment
Structural
drawing
Inadequate
sealing
of
roof
membrane
around
conduit
and
ventilation
ducts
leading
to
local
leakage
around
the
conduit
or
duct.
10553603;a2
Roof
membrane
inadequately
sealed
around
roof
access
hatch.
10553703;a2
Publ.
No.
1558792
Rev
.
a460
–
ENGLISH
(EN)
–
July
1,
2010
137
27
–
Introduction
to
building
thermography
148
150
