9.5
Laser
pointer
General
The
camera
has
a
laser
pointer
.
When
the
laser
pointer
is
on,
you
can
see
a
laser
dot
approximately
40
mm
(1.57
in.)
above
the
target.
Figure
This
figure
shows
the
difference
in
position
between
the
laser
pointer
and
the
optical
center
of
the
infrared
lens:
10759203;a1
18
Publ.
No.
1558792
Rev
.
a460
–
ENGLISH
(EN)
–
July
1,
2010
9
–
Camera
parts
29
31
