FLIR DM166 USER MANUAL Document Identifier: DM166-en-US_AA
29
Power Supply: 3 x 1.5 V AA alkaline or Li/FeS
2
lithium batteries or optional Model TA04 lithium
polymer rechargeable battery system
Power Requirements for thermal imager:
● Battery Type: Alkaline ‘AA’ Battery x 3
Battery Life: approximately 12 hours
● Battery Type: Energizer L91 Lithium (Li/FeS
2
) ‘AA’ Battery x 3
Battery Life: approximately 22 hours
● Optional Rechargeable Battery: Li-Polymer; FLIR PN: TA04-KIT
Battery Life: approximately 22 hours
Power Consumption (typical): 160mA
APO Consumption (typical): 200A
APO Timing: Five (5) minutes (default), 10 minutes, 20 minutes & OFF selectable
APO counter reset for DMM mode:
 Rotary switch or push button operations
 Significant measuring readings of above 8.5% of ranges
 Non-OL readings for Resistance, Continuity or Diode function
 Non-zero readings for Hz function
 Electric field signal present for EF function
APO counter reset for Thermal Imager mode:
Rotary switch or push button operations
Accessories: Test lead pair, Batteries, Quick Start manual, Pouch
Calibration Cycle: One year
Weight: 15.1 oz (428.3g)
Dimensions: (L x W x H) 7.5 x 3.4 x 1.9 in. (190 x 86.4 x 48.3mm)
CAT
Application Field
I
Circuits not connected to mains.
II
Circuits directly connected to a low-voltage installation.
III
Building installation.
IV
Source of the low-voltage installation.
