FLIR DM166 USER MANUAL Document Identifier: DM166-en-US_AA
34
FLEX*
RANGE and RESOLUTION
Accuracy
50Hz ~ 400Hz
30.00A, 300.0A, 3000A
2.0% + 3d
Input Impedance: 10M, 54pF nominal
Non-Contact Voltage EF-Detection
Bar-Graph Indication
EF-H (Hi Sensitivity)
EF-L (Lo Sensitivity)
DMM mode
IGM mode
Typical Voltage (Tolerance)
--
-
20V (10V ~ 30V)
80V (40V ~ 150V)
----
- -
40V (20V ~ 60V)
160V (80V ~ 300V)
------
- - -
80V (40V ~ 150V)
320V (160V ~ 450V)
--------
- - - -
160V (80V ~ 300V)
640V (320V ~ 900V)
---------
- - - - -
320V (>320V)
1000V (>950V)
Indication: Bar-graph segments & audible beep tones proportional to the field strength
Detection Frequency: 50/60Hz
Detection Antenna: Top of meter
10. Technical Support
Main Website
http://www.flir.com/test
Technical Support Website
http://support.flir.com
Technical support Email
TMSupport@flir.com
Service/Repair Support Email
Repair@flir.com
Support Telephone number
+1 855-499-3662 option 3 (toll-free)

FLIR DM166 Specifications

General

Max Voltage (AC)	600 V
Max Voltage (DC)	600 V
Max Current (AC/DC)	10 A
Resistance Measurement	40 MΩ
Temperature Measurement	Yes
Frequency	10 MHz
Data Logging	Yes
VFD Mode	Yes
Continuity	Yes
Diode Test	Yes
LoZ Mode	Yes
Min/Max/Avg	Yes
Bluetooth	No
Type	Digital Multimeter
Display	LCD
IR Resolution	80 x 60 pixels
Emissivity	0.1 to 1.0
Battery Type	AA
Safety Rating	CAT III 600V, CAT IV 300V
Accuracy	±1.5% + 2°C (±2.7°F)
Weight	1.2 lbs (0.54 kg)
Warranty	3-year tool, 10-year detector
