9.2 Thermal Imaging Specifications
IR Temperature Range 14 ~ 302°F (-10 ~150°C)
IR Temperature Resolution 0.1°C/F
Image Sensitivity < or equal to 150mK (0.15°C)
IR Temperature Accuracy ±9°F (±5°C) or ±5% (14~302°F [-10 to 150°C]) whichever is
greater
Emissivity 0.95 maximum (4 presets and a fine tuning feature)
Distance to Spot ratio 30:1
Response time 150ms
Spectral Response 8~14um
Scanning type Continuous
Repeatability 0.5%
Image Detector Lepton
Display resolution 80 x 60 pixels
Field of View (FOV) 38.6
o
x 50
o
Color Palettes Selectable: Iron, Rainbow, and Greyscale
Laser type Class 1
Laser power < 0.4mW
9.3 Electrical Specifications
*Accuracy is given as ± (% of reading + counts of least significant digit) or as otherwise specified at 73.4°F ±9°F
(23°C ± 5°C), with relative humidity < 80%; AC Voltage & Current accuracies are specified from 1 % to 100 % of
range, or as otherwise specified.
Maximum Crest Factor is <2:1 at full scale & <4:1 at half scale, and with frequency components within the
specified frequency bandwidth for non-sinusoidal waveforms
Other AC Function notes:
● ACV and ACA are ac coupled, true RMS
● For all AC functions, the LCD displays 0 counts when the reading < 10 counts
Temperature Coefficient: Nominal 0.15 x (specified accuracy)/
o
C @ 14
o
F ~ 64.4
o
F (-10
o
C ~ 18
o
C) or 82.4
o
F ~
122
o
F (28
o
C ~ 50
o
C), or as otherwise specified
AC Voltage*
