FLIR DM166 USER MANUAL Document Identifier: DM166-en-US_AA
31
VFD_ACV* (with Low Pass Filter)
RANGE and RESOLUTION
Accuracy
1)
10Hz ~ 100Hz (fundamental)
600.0V,
1.0% + 3d
100Hz ~ 400Hz (fundamental)
600.0V,
10% + 3d
2)
1)
Not specified for fundamental frequency > 400Hz
2)
Accuracy linearly decreases from 1% + 3d @100Hz to 10% + 3d @400Hz
ACmV*
RANGE and RESOLUTION
Accuracy
50Hz ~ 60Hz
60.00mV
1) 2)
, 600.0mV
3)
1.0% + 3d
10Hz ~ 500Hz
60.00mV
1) 2)
, 600.0mV
3)
2.0% + 3d
Input Impedance: 10M, 54pF nominal
1)
Non-zero residual readings  5d may appear as a zero volt input (short-circuit) when battery indication is 
25%
2)
Signal peak absolute values, including DC bias: < 130mV
peak
3)
Signal peak absolute values, including DC bias: < 1300mV
peak
DC Voltage
RANGE and RESOLUTION
Accuracy
60.00mV, 600.0mV,
0.3% + 2d
6.000V, 600.0V
0.4% + 2d
60.00V
0.5% + 2d
Input Impedance: 10M, 54pF nominal
Ohm
RANGE and RESOLUTION
1)
Accuracy
600.0
0.3% + 3d
6.000k,60.00k, 600.0k
0.5% + 3d
6.000M
2)
0.9% + 2d
60.00M
3) 4) 5)
1.5% + 2d
1)
Open Circuit Voltage: 1.6VDC typical
2)
Constant Test Current: 0.1A Typical
3)
Constant Test Current: 0.01A Typical
4)
5%+20d @ >30M,
5)
Unspecified @ ambient > 40
o
C

FLIR DM166 Specifications

General

Max Voltage (AC)	600 V
Max Voltage (DC)	600 V
Max Current (AC/DC)	10 A
Resistance Measurement	40 MΩ
Temperature Measurement	Yes
Frequency	10 MHz
Data Logging	Yes
VFD Mode	Yes
Continuity	Yes
Diode Test	Yes
LoZ Mode	Yes
Min/Max/Avg	Yes
Bluetooth	No
Type	Digital Multimeter
Display	LCD
IR Resolution	80 x 60 pixels
Emissivity	0.1 to 1.0
Battery Type	AA
Safety Rating	CAT III 600V, CAT IV 300V
Accuracy	±1.5% + 2°C (±2.7°F)
Weight	1.2 lbs (0.54 kg)
Warranty	3-year tool, 10-year detector
