FLIR DNV14UX2 User Manual

69
Technical Specifications
11. TECHNICAL SPECIFICATIONS
Because our products are subject to continuous improvement, FLIR
Systems, Inc. reserves the right to modify product design and specifications
without notice and without incurring any obligation. E&O.E.
Specifications
UPC: 8-41430-00840-8
Weight: 1.21kg/2.7lbs
Package
Dimensions:
(W x D x H)
170mm x 160mm x 180mm
6.7” x 6.3” x 7.1”
Package Cube: 0.0049 cbm/0.173cu ft
Product Information
Software CD:
Milestone XProtect
®
GO Software
CMS-DH Pro
Syncro-V
Auto Port Forwarding wizard
User Manual
Surface Mounting Template
DC Power Pigtail
What’s Included:
Sensor/DSP:
1/2.5” CMOS Progressive Scan
Day/Night:
True Day/Night with ICR Filter.
High Powered IR LEDs
Resolutions and Max
supported frame rate:
1920x1080 Full HD 2.1MP at 30fps
Min. Illumination:
Color: 0.1 lux@F1.2 @F1.2, AGC on/
(0 Lux IR LED On)
Lens:
2.8-12mm Vari-focal
Horizontal Field of View:
79.3° ~ 29.8°
IR LED:
12pc Super Flux LEDs 850nm
IR Distance:
65 feet/20 Meters
Video Output:
RJ45, Setup/Service BNC Video Out
Electronic Shutter:
Auto/User 1/5 - 1/50,0000
Audio Compression:
G711 A-Law, G711 U-Law, RAW_PCM
Camera
Input/Output:
1 x RCA Input/1 x RCA Audio Output 1v Line
Level
Audio Compression:
G711 A-Law, G711 U-Law, RAW_PCM
Audio
Power:
12v DC, minimum 0.55A
Power over Ethernet:
PoE Class 3, 13W max
Operating Temperature:
-40°F to 122°F/-40ºC to 50ºC
Operating Humidity
10% - 85% RH
Approvals
CE/FCC/RoHS Compliant/IP66/IK10/UL60950
Product Dimensions
5.1 x 4.4”/130 x 112 mm
Product Weight
0.85kg/1.87lb
General
Compression:
H-264 High Profile (Support Baseline Profile/
MJPEG)
Bit Rate (CBR/VBR):
Stream1 50Kbps - 12Mbps ; Stream2 10Kbps
- 6Mbps ; Stream3 (MJPEG Fixed)
Quality Setting:
1 - 9 (9 Highest)
Multi- Streaming:
User setting of Stream 1/2 at supported
Resolutions, Stream3 fixed MJPEG Stream
Brightness/Sharpness:
Variable 0~100/0~100
Gain Control:
Auto/Fixed 8~102db
Orientation:
Horizontal Mirror/Vertical Flip
Text Overlay:
Time/Date/Camera/Custom OSD
Masking:
3 User defined masking areas < 8% of total
Video
Ethernet:
1 Ethernet (10/100 Base-T) RJ-45 Connector
one network coupler supplied
TCP/IP:
IPv4/IPv6 (DHCP/Fixed)
Compliance:
Onvif 2.1 (1.02 backward compatible)
RTSP Video:
Standard RFC2326, Support QuickTime/VLC
Player. User security authentication (Enabled/
Disabled)
Web Language:
English, Chinese, Russian, Polish
Recording Simultaneous:
Local microSD Memory*, Remote FTP server,
TCP/UDP CMS, RTSP connection (stream 1,2 or 3)
Network Protocols:
HTTP, TCP/IP, UDP/IP, RTSP, FTP, DHCP, NTP,
PPoE.
Video streaming from SDK & NVMS/NVR
software or 3rd party applications.
User Ports setting for Web port, RTSP Port,
and SDK Control Port and Alarm Port.
Network
Dimensions
112mm/
4.4”
130mm/
5.1”
MNTV2XB Junction Box
MNTV2XC Ceiling Mount
MNTV2XW Wall Mount
MNTV2XP Pole Mount
MNTV2XPC Pendant Cap
MNTV2XR Corner Mount
Accessories:
MNTV2XB Shown
*microSD card not included. Up to 64GB.
