432-0003-00-12 Rev 140 — M-Series Installation Guide 19
M-Series Reference
External Standards
Table 2.2 lists other sources of information and standards definitions that may be
useful during the installation of your M-Series camera.
Power
Camera Input Power 12 – 24 V DC nominal, 5 A Max
Absolute range 10 – 32V DC
(–10%/+30% per IEC 60945)
Camera Output Power (to
JCU)
Power Over Ethernet (PoE) per IEEE 802.3af
48V mode B PoE, RJ45
JCU Input Power Power over Ethernet (PoE) per IEEE 802.3af
Consumption 25W Nominal
42W Max (dual payload)
Environmental
Operating temperature
range
–25° C to +55° C (–11° F to +131° F)
Storage temperature range –40º C to +85º C (–38º F to +185º F)
Automatic Window defrost Standard (automatic at unit power-up)
Sand/dust Mil-Std-810E
Automatic Window de-icing Standard (automatic at unit power-up)
Water Ingress IPX 6
Shock 15 g vertical, 9 g horizontal
Vibration IEC 60945; MIL-STD-810E
Lightening Protection Standard
Salt Mist IEC 60945
Wind 100 knot (115.2 mph)
EMI IEC 60945
TABLE 2.2 External References
Standard Description
ANSI/SCTE 01 2006 “F”
Port, Female, Outdoor
http://www.scte.org
IEC 60169-24 Radio-frequency coaxial connectors with screw coupling,
typically for use in 75 Ohm cable distribution systems
(Type F)
TABLE 2.1 Specifications
