432-0003-00-12 Rev 140 — M-Series Installation Guide 5
Installing M-Series Systems
Note: Notes call attention to information that is especially significant to
understanding and operating the equipment.
Warnings and Cautions
Warning: Do not use the M-Series imaging system as the primary navigation
system. Use it in conjunction with other navigation aids and a primary manual
navigation system.
Warning: Use of insufficient wire gauge can result in fire.
Caution: Do not open the M-Series camera unit for any reason. Disassembly of
the camera (including removal of the cover) can cause permanent damage and
will void the warranty.
Caution: Be careful not to leave fingerprints on the M-Series camera optics.
Caution: The M-Series requires a power supply of 12 – 24V DC nominal, 5 Amp
maximum. Absolute voltage range: 10 – 32V DC. Operating the camera outside of
the specified input voltage range or the specified operating temperature range
can cause permanent damage.
Caution: During installation, ensure the cables exiting the bottom of the camera
are not in contact with sharp edges, do not bend at sharp angles, and are not
pinched between the bottom of the camera and the mounting surface. Do not pull
on the cables with excessive force.
Proper Disposal of Electrical and Electronic Equipment (EEE): The European
Union (EU) has enacted Waste Electrical and Electronic Equipment Directive
2002/96/EC (WEEE), which aims to prevent EEE waste from arising, to
encourage reuse, recycling, and recovery of EEE waste, and to promote
environmental responsibility.
In accordance with these regulations, all EEE products labeled with the “crossed
out wheeled bin” either on the product itself or in the product literature must not be
disposed of in regular rubbish bins, mixed with regular household or other
commercial waste, or by other regular municipal waste collection means. Instead,
and in order to prevent possible harm to the environment or human health, all
EEE products (including any cables that came with the product) should be
responsibly discarded or recycled.
To identify a responsible disposal method where you live, please contact your
local waste collection or recycling service, your original place of purchase or
product supplier, or the responsible government authority in your area. Business
users should contact their supplier or refer to their purchase contract.
