ORION SC7000 User Manual
DCOO5U-F ORION SC7000 User Manual Page 22
 Peel the needed shims (0.1 mm per shim) as indicated
below:
Place the cutter blade edge
on the peelable spacer as
shown above
Move the cutter blade
towards your thumb and peel
the shim as shown above
