ORION SC7000 User Manual
DCOO5U-F ORION SC7000 User Manual Page 25
c. One 2mm thick filter
(1) Place the spacer ring #2
in the slot
(5) Then place carefully the
filter on top of the
spacer ring
(6) Put the slot ring
according to step
§6.3.1.5
(7) Follow instructions from
step §6.3.1.4 to step
§6.3.1.1
(1)
(2)
