FLIR PT series User Manual

427-0075-01-12 Revision 140 October 2019 16
This document does not contain any export-controlled information.
PT-Series HD Camera Installation
Other Serial Communication Parameters: The tables below defines the switch locations, bit
numbering and on/off settings used in controlling the other serial communication parameters.
Table 1-3: Dip Switch Settings—SW103
Settings Description
Baud rate:
Bit 1 Bit 2
OFF OFF
ON OFF
OFF ON
ON ON
Camera Control Protocol:
Bit 3 Bit 4
OFF OFF
ON OFF
OFF ON
ON ON
Serial Communication Standard:
Bit 5 Bit 6
OFF OFF
ON OFF
OFF ON
ON ON
Bit 7 Bit 8
X X
X X
X X
X X
Software Override DIP Switch:
Bit 9
OFF
ON
Bit 10
X
Table 1-2: Dip Switch Address/ID Settings—SW101
