FLIR Raymarine CPT-S Transom User Manual

2.1Documentinformation
Thisdocumentcontainsimportantinformation
relatedtotheinstallationofyourRaymarineproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthe
necessaryequipment;
•installandconnectyourproductaspartofawider
systemofconnectedmarineelectronics;
•troubleshootproblemsandobtaintechnical
supportifrequired.
ThisandotherRaymarineproductdocuments
areavailabletodownloadinPDFformatfrom
www.raymarine.com.
CPT-STransomtransducer
D13507-1
Part
numberDescription
Construc-
tion
E70342
CPT-S—TransomCHIRPsonar
transducer
Plastic
•TheCPT-SisaCHIRP ,conicalbeamsonar
transducer
•Thetransducercanbeconnectedto
DownVision
™
sonarmodulesorDownVision
™
variantMFDsrunningLightHouseIIVersion
16software,offeringsonaronlyfunctionalityto
DownVision
™
products.
Documentillustrations
Yourproductmaydifferslightlyfromthatshown
intheillustrationsinthisdocument,dependingon
productvariantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
Productdocumentation
Thefollowingdocumentationisapplicabletoyour
product:
DescriptionPartnumber
CPT–StransducerInstallationinstructions
InstallationofaCPT–Stransducerand
connectiontoasonarmodule/display.
87263/
88059
LightHouseMFDoperationinstructions
DetailstheoperationoftheFishnder
applicationforLightHouse
™
powered
DownVision
™
variantmultifunctiondisplays.
81360
Operationinstructions
Fordetailedoperationinstructionsforyourproduct,
refertothedocumentationthataccompaniesyour
display.
Sonarmoduleinstallationinstructions
Thisdocumentincludesinstallationinstructionsfor
thetransduceronly.Forinstallationinstructions
forconnectingasonarmodule,pleaserefertothe
documentationthataccompaniesthesonarmodule.
10CPT-STransomCHIRPsonartransducer
