4.3Connectionsoverview
Usethefollowinginformationtohelpyouidentifythe
connectionsonyourproduct.
ConnectorConnectortypeConnectsto:
9pin
DownVision
™
typeconnector
DownVision
™
sonar
moduleorMFD
Makingconnections
Followthestepsbelowtoconnectthecable(s)to
yourproduct.
1.Ensurethatthevessel'spowersupplyisswitched
off.
2.Ensurethatthedevicebeingconnectedtothe
unithasbeeninstalledinaccordancewiththe
installationinstructionssuppliedwiththatdevice.
3.Ensuringcorrectorientation,pushthecable
connectorfullyontothecorrespondingconnector
ontheunit.
4.Turnthelockingcollarclockwisetosecurethe
cable.
Transducercableextension
Forbestperformance,cablerunsshouldbekeptto
aminimum.However,forsomeinstallationsitmay
benecessarytoextendthetransducercable.
•A4m(13.1ft.)Transducerextensioncable
(A80273)isavailable.
•Itisrecommendedthatonlyonecableextension
isused.
Cablesandconnections
