3.1Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem.
2
Obtainallrequiredequipmentandtools.
3
Siteallequipment.
4Routeallcables.
5
Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7
Secureallequipmentinplace.
8Poweronandtestthesystem.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanning
anyinstallation.Itisalsousefulforanyfuture
additionsormaintenanceofthesystem.The
diagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
3.2Partssupplied–CPT-S
D13460-1
2 3
9
10
x3
41 5 6 7 8
1.Transducer
2.Ratchetarm
3.Mountingbracket
4.M5Hexratchetbolt
5.Ratchetplate
6.Compressionwasher
7.M5washer
8.M5lockingnut
9.3xSelftappingscrews
10.Documentation
14
CPT-STransomCHIRPsonartransducer
